Mosa Magic Weld 150A



The Mosa Magic Weld 150A DC arc welding machine is a lightweight and compact welding generator.  Designed for professionals, with the capability of delivering up to 150 A with a duty cycle of 60%.

• Portable DC arc welding machine
• Welding with any type of electrode including cellulostic electrodes
• High-frequency voltage control and welding current
• High-performance permanent magneto alternator
• 110V DC Auxiliary current with micro-breaks for tool protection
• Quiet running Honda GX200 Engine
• Fuel Type: Gasoline
• Low oil level engine stop switch
• Economizer function
• Power Optimizer
• CE Certified
• Permanent magnet alternator, self-excited, brushless
• Dinse cable connectors included
• Two year Mosa Warranty
• Made in Italy

• Adjustment Range		30 – 150A
  Duty Cycle		150A – 60%
  Fuel Tank Size		3.11L (3 hours welding time)
  Trigger Voltage		67V
  Single Phase Power Max		2KW 230V cc 8.7A
  Continuous Single Phase Power		1.6KW 230V cc 6.9A
  Auxiliary Power		1x 110V DC, 1.5kW, 13.6A
  Dimension		420 x 360 x 480 MM 16.5 x 14.25 x 18.75 IN
  Weight		34 Kg 75 Lbs
